IP DSLAM
641
Mode:
Super-User, User.
Example:
$ get trace stats
Output:
Verbose Mode On/Off
Bytes Logged: 2744 Bytes Discarded : 40595
Msgs Logged : 19 Msgs Discarded : 1045
Output Fields:
FIELD Description
Bytes Logged
This specifies the number of bytes logged by the
tracing/logging module.
Bytes Discarded
This specifies the number of bytes discarded by
the tracing/ logging module due to filtering.
Msgs Logged
This specifies the number of message logged by
the tracing/ logging module.
Msgs Discarded
This specifies the number of messages discarded
by the tracing/logging module due to filtering.
References:
z get trace cfg command
z Modify trace cfg command.
