IDL series User Guide
690
Output Fields:
None
Caution:
Currently help is not available between a parameter name and its value.
5.28.2.3 Logout
Description:
Use this command to exit from the CLI shell.
Command Syntax:
logout | quit | exit
5.28.2.4 Prompt
Description:
Use this command to set the new CLI prompt.
Command Syntax:
prompt <new-prompt>
Parameters:
Name Description
prompt <new-prompt>
The new prompt string.
Type: Mandatory
Valid values: String of up to 19 characters ( All characters except ‘;’, ‘ ‘, ‘?’)
Mode :
Super-User, User
Example :
$ prompt $$$
Output:
Set Done
$$$
Output Fields:
None
