6.3.4 Trap Receivers
This page lists the parameters for SNMP trap receivers (For SNMP Network Management).
Option Description
Index
The index number of the entry in the table.
NMS IP Address
The IP Address in dotted format of the NMS station to which the trap
should be sent.
Community String
The community string of the trap PDU to be sent. The maximum
length of the string is 19 characters.
Trap Type
Types of the traps to be received. Set the type of the trap.
[None]: Traps are not be received.
[IP Power Manager Trap]: Traps are received base on IP Power
Manager MIB.
Severity
Set the level of the trap to be received.
[Information]: All traps are received.
[Warning]: Trap that need to be noticed and are in dangerous is
received.
[Severe]: The significant traps such as the outlet voltage over
threshold are received.
Description
Customer description string.
- 27 -
