Si37-701 Special Control
Function 117
Cooling indoor unit actuator Oil return operation
Fan
Thermo ON unit Remote controller setting
Unit not in operation OFF
Thermo OFF unit Remote controller setting
Motorized valve
Thermo ON unit Normal opening degree
Unit not in operation 192pls
Thermo OFF unit Normal opening degree for forced thermostat ON
Heating indoor unit actuator Oil return operation
Fan
Thermo ON unit Remote controller setting
Unit not in operation OFF
Thermo OFF unit LL
Motorized valve
Thermo ON unit Normal opening degree
Unit not in operation 224 pls
Thermo OFF unit Normal opening degree for forced thermostat ON
Cooling BS unit actuator Elect. symbol Oil return operation
Electronic expansion vale (EVH) Y4E 0pls
Electronic expansion vale (EVL) Y5E 760pls
Electronic expansion vale (EVHS) Y2E 0pls (60pls when Pc_max>2.85MPa)
Electronic expansion vale (EVLS) Y3E 480pls
Electronic expansion vale (EVSC) Y1E PI control
Heating BS unit actuator Elect. symbol Oil return operation
Electronic expansion vale (EVH) Y4E 760pls
Electronic expansion vale (EVL) Y5E 0pls
Electronic expansion vale (EVHS) Y2E 60pls
Electronic expansion vale (EVLS) Y3E 0pls (60pls when Pc_max>2.85MPa)
Electronic expansion vale (EVSC) Y1E
0pls (PI control at simultaneous cooling / heating
operation)
