Si37-701 Field Setting
Test Operation 177
(10) Air Flow When Cooling Thermostat is OFF
This is used to set air flow to "LL air flow" when cooling thermostat is OFF.
(11) Setting of Normal Air Flow
Make the following setting according to the ceiling height. The setting position No. is set to “01”
at the factory.
In the Case of FXAQ, FXHQ
In the Case of FXFQ25~80
In the Case of FXFQ100~125
(12) Air Flow Direction Setting
Set the air flow direction of indoor units as given in the table below. (Set when optional air outlet
blocking pad has been installed.) The second code No. is factory set to “01.”
Setting Table
(13) Operation of downward flow flap: Yes/No
Only the model FXKQ has the function.
When only the front-flow is used, sets yes/no of the swing flap operation of down-flow.
Setting Table
Mode No. First Code No. Second Code No. Contents
12 (22) 6
01 LL air flow
02 Preset air flow
Mode No.
Setting Switch
No.
Setting Position
No.
Setting
13(23) 0
01 Wall-mounted type: Standard
02 Wall-mounted type: Slight increase
03 Wall-mounted type: Normal increase
Mode
No.
First
code
No.
Second
code
No.
Setting
Ceiling height
4-way Outlets 3-way Outlets 2-way Outlets
13 (23) 0
01 Standard (N) Lower than 2.7 m Lower than 3.0 m Lower than 3.5 m
02 High Ceiling (H) Lower than 3.0 m Lower than 3.3 m Lower than 3.8 m
03 Higher Ceiling (S) Lower than 3.5 m Lower than 3.5 m —
Mode
No.
First
code
No.
Second
code
No.
Setting
Ceiling height
4-way Outlets 3-way Outlets 2-way Outlets
13 (23) 0
01 Standard (N) Lower than 3.2 m Lower than 3.6 m Lower than 4.2 m
02 High Ceiling (H) Lower than 3.6 m Lower than 4.0 m Lower than 4.2 m
03 Higher Ceiling (S) Lower than 4.2 m Lower than 4.2 m —
Mode No. First Code No.
Second Code
No.
Setting
13 (23) 1
01 F : 4-direction air flow
02 T : 3-direction air flow
03 W : 2-direction air flow
Mode No. First Code No. Second Code No. Setting
13 (23) 3
01 Down-flow operation: Yes
02 Down-flow operation: No
