Protection Control Si37-701
130 Function
[Inverter fin temperature control]
★
Perform the following control of integrated as well as multi units for each INV compressor.
Normal operation
During the control of fin
temperature protection
Tfin<81˚C
INV upper limit frequency=max (210Hz)
&
Tfin>84˚C
INV Comp. upper limit
step: 1-step up
Tfin<81˚C
continues for 3 minutes
Current status
maintained
10 seconds
INV Comp. upper limit step:
1-step down
Tfin>84˚C
Tfin>93˚C
Fin temperature standby
When occuring 4 times within 60 min., the
malfunction code “L4” is output.
