Test Operation Si37-701
162 Test Operation
6. After completing the additional refrigerant charging, record the charging amount on the
accessory “REQUEST FOR THE INDICATON” label (Installation records) and adhere it to
the back side of the front panel. Also, record the factory charged refrigerant amount,
additional refrigerant amount in the field and total refrigerant amount of the system to
“ADDITIONAL REF. CHARGE” label and adhere in the proximity of the refrigerant charge
port. About “ADDITIONAL REF. CHARGE” label.
1.2.5.2.2 Procedure of check operation
Check operation perform the following work. Do the check operation following below.
Otherwise, malfunction code “U3” will be displayed in the remote controller and nomal
operation can not be carried out.
• Check of shutoff valve opening
• Check of miswiring
• Judgment of piping length
• Check of refrigerant overcharge
Note:
Check operation can not carried out at outdoor temp. less than -5°C.
Perform the check operation at day or time that outdoor temp. is -5°C or more.
[Check Operation Procedure]
1. Close the EL. COMPO. BOX lid and all front panels except as the side of the EL. COMPO.
BOX and turn on the power to the outdoor unit and all connected BS, indoor units. (Be sure
to turn the power on at least 6 hours before operation in order to have power running to the
crank case heater.)
2. Make the onsite settings as needed using the push button (BS1-BS5) on the outdoor unit
PC-board (A1P) with the power on. (See “1.2.6 Onsite Settings”)
3. Perform the check operation following the Check Operation Method of the [Service
Precautions] label (lower) on the EL. COMPO. BOX lid. The system operation for about
40~60 minutes and automatically stops the check operation.
If the malfunction code is not displayed in the remote controller after the system stop, check
operation is completed. Normal operation will be possible after 5 minutes. If the malfunction
code is displayed in the remote controller, correct the malfunction following [Remote
controller displays malfunction code] and perform the check operation again.
Note:
For interrupting the check operation, push RETURN button (BS3).
Check operation method
[Note]
Make sure to open the equalizer (only for Multi system), suction pipe, dual pressure gas
pipe and liquid pipe shutoff valves completely.
• In the check operation, the following works will be automatically performed.
Check of miswiring / Check of shutoff valve opening / Check of refrigerant overcharge /
Judgment of piping length
• Make sure to carry out the check operation after the first installation.
Otherwise, the malfunction code "U3" will be displayed in the remote controller and normal
operation cannot be carried out.
When the check operation is finished normally, normal operation can be carried out after 5
minutes.
• For Multi system, check the setting and result on the master unit. (See
)
• The abnormality of each indoor unit can not be checked. After the check operation is finished,
check the indoor units individually by normal operation using the remote controller.
[Operation procedure]
To protect the compressor, make sure to turn on the power supply for 6 hours before stating
operation.
(After turning on the power supply, the unit can not start the operation until the H2P LED
goes off. (maximum 12 minutes))
Caution for Multi
connecting system
