Model Names of Indoor/Outdoor Units Si37-701
2 General Information
1. Model Names of Indoor/Outdoor Units
Indoor Units
Note: FXDQ has following 2 Series, as show below.
FXDQ-P, N(A)VET: without Drain Pump (For General, Asia: except for EU, China and Australia)
FXDQ-P, N(A)VE: with Drain Pump
MA, NA: RoHS Directive models; Specifications, Dimensions and other functions are not changed compared
with M, N type.
FXZQ: only for EU Australia
FXDYQ: only for Australia
BS Units
Outdoor Units
Normal Series
YE : 1
φ
, 220 ~ 240V, 50Hz / 220V, 60Hz
V1 : 1
φ
, 220 ~ 240V, 50Hz
Y1 : 3
φ
, 380 ~ 415V, 50Hz
Type Model Name
Power
Supply
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M 80M — 125M — — — —
VE
Ceiling Mounted
Cassette Type
(Multi Flow)
FXFQ — 25M 32M 40M 50M 63M 80M 100M 125M — — — —
600×600 Ceiling
Mounted Cassette
Type
FXZQ20M825M832M840M850M8————————V1B
Ceiling Mounted
Cassette Corner Type
FXKQ—25MA32MA40MA—63MA———————
VE
Slim Ceiling Mounted
Duct Type
FXDQ-
PVE
20P25P32P——————————
FXDQ-
PVET
20P25P32P——————————
FXDQ-
NAVE
20NA25NA32NA40NA50NA63NA———————
FXDQ-
NVET
20N25N32N40N50N63N———————
Ceiling Concealed
(Duct) Type (Aus.
exclusive use)
FXDYQ——————80M100M 125M 145M 180M 200M 250M V1
Ceiling Mounted
Built-In Type
FXSQ 20M 25M 32M 40M 50M 63M 80M 100M 125M — — — —
VE
Ceiling Mounted
Duct Type
FXMQ — — — 40MA 50MA 63MA 80MA
100MA 125MA
——
200MA 250MA
Ceiling Suspended
Type
FXHQ — — 32MA — — 63MA —
100MA
—————
Wall Mounted Type
FXAQ20MA25MA32MA40MA50MA63MA———————
Floor Standing Type
FXLQ20MA25MA32MA40MA50MA63MA———————
Concealed Floor
Standing Type
FXNQ20MA25MA32MA40MA50MA63MA———————
Type Model Name Power Supply
Heat Recovery Series
BSVQ 100P 160P 250P V1
Series Model Name Power Supply
Heat Recovery REYQ
8P 10P 12P 14P 16P 18P 20P 22P 24P
Y1(E)26P 28P 30P 32P 34P 36P 38P 40P 42P
44P 46P 48P
E: The unit with anti corrosion treatment
