Si37-701 Special Control
Function 119
Evaporating outdoor unit actuator Symbol
Elect.
symbol
Defrost operation Operation after defrost
Compressor 1
—
M1C
REYQ8•10•12P: 232Hz+ON
REYQ14•16P: 232Hz+232Hz
REMQ8P: 210Hz
REMQ10•12P: 210Hz+ON
REMQ14•16P: 210Hz+ON+ON
Upper limit 124Hz (STD Holds)
REYP400•480A: 232Hz+232Hz
REMP224A: 210Hz
REMP280•335A: 210Hz+ON
REMP400•450A:
210Hz+ON+ON
Compressor 2 M2C
Compressor 3 M3C
Outdoor unit fan 1
—
M1F
Fan control Fan control
Outdoor unit fan 2 M2F
Four way valve (for heat changer
selection)
20SA
Y2S
Y9S
ON ON
Four way valve (for high- and low-
pressure gas pipe selection)
20SB Y8S Holds Holds
Electronic expansion valve (main) EVM
Y1E
Y3E
PI control PI control
Electronic expansion valve
(subcooling)
EVT
Y2E
Y5E
SH control 0pls
Electronic expansion valve (refilling
refrigerant)
EVJ Y4E 80pls 80pls
Solenoid valve (main bypass) SVE
Y5S
Y10S
OFF OFF
Solenoid valve (hot gas) SVP Y4S OFF OFF
Solenoid valve (liquid pipe of
refrigerant regulator)
SVL Y3S 0pls 0pls
Solenoid valve (gas discharge pipe of
refrigerant regulator)
SVG Y1S 0pls 0pls
Solenoid valve (drain pipe of
refrigerant regulator)
SVO Y7S 0pls 0pls
Solenoid valve (discharge pipe of
refrigerant regulator)
SVT Y6S 0pls 0pls
Cooling indoor unit actuator Defrost operation
Fan
Thermo ON unit Remote controller setting
Unit not in operation OFF
Thermo OFF unit Remote controller setting
Motorized valve
Thermo ON unit Normal opening degree
Unit not in operation 0pls
Thermo OFF unit 0pls
Heating indoor unit actuator
Defrost operation
REYQ REMQ
Fan
Thermo ON unit OFF LL
Unit not in operation OFF LL
Thermo OFF unit OFF LL
Motorized valve
Thermo ON unit 0pls 224pls
Unit not in operation 0pls 0pls
Thermo OFF unit 0pls 224pls
Cooling BS unit actuator Elect. symbol Defrost operation
Electronic expansion vale (EVH) Y4E 0pls
Electronic expansion vale (EVL) Y5E 760pls
Electronic expansion vale (EVHS) Y2E 0pls
Electronic expansion vale (EVLS) Y3E 480pls
Electronic expansion vale (EVSC) Y1E 0pls
Heating BS unit actuator Elect. symbol Defrost operation
Electronic expansion vale (EVH) Y4E 760pls
Electronic expansion vale (EVL) Y5E 0pls
Electronic expansion vale (EVHS) Y2E 60pls
Electronic expansion vale (EVLS) Y3E 0pls (REYQ8~16P) 60pls (REMQ8~16P)
Electronic expansion vale (EVSC) Y1E 0pls (PI control for cool/heat concurrent operation)
