Daikin RXYMQ36MVJU [10/19] Program dry operation

Program DRY Operation

Program DRY is a function that alternates between weak cooling and stopping the unit to remove humidity from

the air, in order to prevent the room temperature from dropping and becoming too cold.

• The microcomputer automatically controls the temperature and fan strength, so these cannot be set using the

remote controller.

• This function is not available if the room temperature is 60°F or lower.

FOR SYSTEMS WITHOUT COOL/HEAT CHANGEOVER REMOTE CONTROLLER

Press OPERATION MODE SELECTOR button several times and select “ ” (PROGRAM DRY Operation).

Press ON/OFF button.

OPERATION lamp lights up and system starts OPERATION.

FOR SYSTEMS WITH COOL/HEAT CHANGEOVER REMOTE CONTROLLER

Select cooling operation mode with the cool/heat changeover remote controller.

Press OPERATION MODE SELECTOR button several times and select “ ” (PROGRAM DRY Operation).

3. Press ON/OFF button.

OPERATION lamp lights up and system starts OPERATION.

Press AIR FLOW DIRECTION ADJUST button.

(only for FXFQ, FXHQ, FXAQ)

Refer to page 10 for details.

Press ON/OFF button again.

OPERATION lamp goes off, and the system stops OPERATION.

ATTENTION:

•

Do not turn OFF power immediately after the unit stops. Then, wait on less than 5 minutes. Water is leaking or there

is something else wrong with the unit.

TEST

Adjustment

STOPPING THE SYSTEM
