2
WARNING
WARNINGWARNING
• It is not good for your health to expose your
body to the air flow for a long time.
• Ask your dealer for installation of the air con-
ditioner.
Incomplete installation performed by yourself may
result in a water leakage, electric shock, and fire.
• Ask your dealer for improvement, repair, and
maintenance.
Incomplete improvement, repair, and mainte-
nance may result in a water leakage, electric
shock, and fire.
• Improper installation or attachment of equip-
ment or accessories could result in electric
shock, short-circuit, leaks, fire or other dam-
age to the equipment. Be sure only to use
accessories made by Daikin which are specifi-
cally designed for use with the equipment and
have them installed by a professional.
• Ask your dealer to move and reinstall the air
conditioner.
Incomplete installation may result in a water leak-
age, electric shock, and fire.
• Never let the indoor unit or the remote control-
ler get wet.
It may cause an electric shock or a fire.
• Never use flammable spray such as hair spray,
lacquer or paint near the unit.
It may cause a fire.
• Never replace a fuse with that of wrong ampere
ratings or other wires when a fuse blows out.
Use of wire or copper wire may cause the unit to
break down or cause a fire.
• Never remove the fan guard of the unit.
A fan rotating at high speed without the fan guard
is very dangerous.
• Never inspect or service the unit by yourself.
Ask a qualified service person to perform this work.
• Cut off all electric waves before maintenance.
• To avoid the risk of serious electric shock,
never sprinkle or spill water or liquids on the
unit.
• Operating the air conditioner with wet hands
could result in a shock hazard.
• Do not allow children to play on or around the
unit as they could be injured.
• The heat exchanger fins are sharp enough to
cut.
To avoid injury, wear gloves or cover the fins while
working around them.
• Do not put a finger or other objects into the air
inlet or air outlet. The fan is rotating at high
speed and will cause injury.
• Do not allow children to play on or around the
unit as they could be injured.
• Operating the air conditioner with wet hands
could result in a shock hazard.
• Check the unit stand for damage on a continu-
ous basis, especially if it has been in use for a
long time.
If left in a damaged condition the unit may fall and
cause injury.
• Placing a flower vase or other containers with
water or other liquids on the unit could result
in a shock hazard or fire if a spill occurs.
• Do not touch the air outlet or horizontal blades
while the swing flap is in operation because
fingers could get caught and injured.
• Be sure to establish an earth.
Do not earth the unit to a utility pipe, arrester, or
telephone earth.
Incomplete earth may cause electrical shock, or
fire.
A high surge current from lightning or other
sources may cause damage to the air conditioner.
• Be sure to install an earth leakage breaker.
Failure to install an earth leakage breaker may
result in electric shocks, or fire.
• Never touch the internal parts of the controller.
Do not remove the front panel because some
parts inside are dangerous to touch. In addition,
some parts may be damaged to touching. For
checking and adjusting internal parts, contact your
dealer.
CAUTION
• Do not use the air conditioner for other pur-
poses.
In order to avoid any quality deterioration, do not
use the unit for cooling precision instruments,
food, plants, animals or works of art.
• Do not place items under the indoor unit which
may be damaged by water.
Condensation may form if the humidity is above
80% or if the drain outlet gets blocked.
01_EN_3PN00286-12Z.fm Page 2 Wednesday, September 14, 2005 8:56 PM
