Product Specification SiE00-01
8 Product Specification
Test conditions are as follows
Notes:
1. Operation sound is measured at 1.5 m below the center the body.
2. Fan speed can be changed over to Low mode or High mode.
3. Operating sound is measured in an anechoic chamber.
Operating sound level generally become greater than this value depending on the operating conditions,
reflected sound, and peripheral noise.
4. The sound level at the air discharge port is about 8 dB higher than the unit’s operating sound.
(50 / 60Hz)
Model Name VAM1000FJVE VAM1500FJVE VAM2000FJVE
Power Supply Single Phase 220 – 240 V / 220 V, 50 / 60 Hz
Temperature Exchanging
Efficiency
Ultra-High % 75 / 75 75 / 75 75 / 75
High % 75 / 75 75 / 75 75 / 75
Low % 76.5 / 78 78 / 78 78 / 78
Enthalpy
Exchange
Efficiency
Cooling Ultra-High % 61 / 61 61 / 61 61 / 61
High % 61 / 61 61 / 61 61 / 61
Low % 63 / 66 64 / 64 66 / 66
Heating Ultra-High % 66 / 66 66 / 66 66 / 66
High % 66 / 66 66 / 66 66 / 66
Low % 68 / 71 68 / 68 70 / 70
Casing Galvanized Steel Plate
Insulating Material Self-extinguishable Urethane Foam
Dimensions H
∞
W
∞
D mm 348 x 988 x 1140 710 x 1498 x 852 710 x 1498 x 1140
Heat Exchanging System Air to Air Cross Flow Total Heat (Sensible Heat + Latent Heat) Exchange
Heat Exchanging Element Specially Processed Nonflammable Paper
Air Filter Multidirectional Fibrous Fleeces
Fan Type Sirroco Fan
Fan
Speed
Ultra-High m
∏
/ h 1000 / 1000 1500 / 1500 2000 / 2000
High m
∏
/ h 1000 / 1000 1500 / 1500 2000 / 2000
Low m
∏
/ h 870 / 800 1200 / 1200 1400 / 1400
External
Static
Pressure
Ultra-High Pa 157 / 196 137 / 206 137 / 196
High Pa 98 / 108 98 / 118 78 / 88
Low Pa 78 / 69 49 / 69 59 / 69
Fan Motor Type Open Type Capacitor Permanent Split-phase Induction Motor, 4 Poles
∞
2
Motor Output kW 0.230
∞
2 0.230
∞
4 0.230
∞
4
Operating
Sound
Heat
Exchange
Mode
Ultra-High dBA 36 – 37 / 37 39.5 – 41.5 / 40.5 40 – 42.5 / 41
High dBA 35 – 36 / 35 38 – 39 / 38 38 – 41 / 38
Low dBA 31 – 32 / 30 34 – 36 / 33 35 – 37 / 35
Byapss
Mode
Ultra-High dBA 36 – 37 / 37 40.5 – 41.5 / 40.5 40 – 42.5 / 41
High dBA 35.5 – 36 / 35 38 – 39 / 38 38 – 41 / 38
Low dBA 31 – 32 / 31 33.5 – 36 / 33 35 – 37 / 35
Operation Range (Ambient) – 10
°
C to 50
°
CDB (80% RH or Less)
Connection Duct Diameter mm
φ
250
φ
350
φ
350
Weight kg 61 132 158
Drawing Number 4D020377A 4D020526A 4D020527A
Condition
Indoor unit Outdoor unit
°
CDB R.H (%)
°
CDB R.H (%)
Cooling condition 27 50 35 60
Heating condition 20 40 7 70
