Daikin VAM2000FAVE [10/81] Product introduction
![Daikin VAM1500FAVE [10/81] Product introduction](/views2/1719068/page10/bga.png)
1. Product introduction
1.4 Selection Procedures 9
1
1.4
<Table 3> Criteria for Model Selection
Required
ventilating AFR
per person
(m
3
/ h / person)
Area per person
(m
2
/ person)
Model Name
Frequency Air Flow Rate
Application area (m
2
)
Hz L H
20
3
VAM 150FAVE
50 110 150 16.5 – 22.5
60 110 150 16.5 – 22.5
VAM 250FAVE
50 155 250 23.3 – 37.5
60 145 250 21.8 – 37.5
VAM 350FAVE
50 230 350 34.5 – 52.5
60 210 350 31.5 – 52.5
VAM 500FAVE
50 350 500 52.5 – 75.0
60 300 500 45.0 – 75.0
VAM 650FAVE
50 500 650 75.0 – 97.5
60 440 650 66.0 – 97.5
VAM 800FA5VE
50 670 800 100.5 – 120.0
60 660 800 99.0 – 120.0
VAM1000FA5VE
50 870 1000 130.5 – 150.0
60 800 1000 120.0 – 150.0
VAM1500FA5VE
50 1200 1500 180.0 – 225.0
60 1200 1500 180.0 – 225.0
VAM2000FA5VE
50 1400 2000 210.0 – 300.0
60 1400 2000 210.0 – 300.0
5
VAM 150FAVE
50 110 150 27.5 – 37.5
60 110 150 27.5 – 37.5
VAM 250FAVE
50 155 250 38.8 – 62.5
60 145 250 36.3 – 62.5
VAM 350FAVE
50 230 350 57.5 – 87.5
60 210 350 52.5 – 87.5
VAM 500FAVE
50 350 500 87.5 – 125.0
60 300 500 75.0 – 125.0
VAM 650FAVE
50 500 650 125.0 – 162.5
60 440 650 110.0 – 162.5
VAM 800FA5VE
50 670 800 167.5 – 200.0
60 660 800 165.0 – 200.0
VAM1000FA5VE
50 870 1000 217.5 – 250.0
60 800 1000 200.0 – 250.0
VAM1500FA5VE
50 1200 1500 300.0 – 375.0
60 1200 1500 300.0 – 375.0
VAM2000FA5VE
50 1400 2000 350.0 – 500.0
60 1400 2000 350.0 – 500.0
10
VAM 150FAVE
50 110 150 55.0 – 75.0
60 110 150 55.0 – 75.0
VAM 250FAVE
50 155 250 78.0 – 125.0
60 145 250 72.0 – 125.0
VAM 350FAVE
50 230 350 115.0 – 175.0
60 210 350 105.0 – 175.0
VAM 500FAVE
50 350 500 175.0 – 250.0
60 300 500 150.0 – 250.0
VAM 650FAVE
50 500 650 250.0 – 325.0
60 440 650 220.0 – 325.0
VAM 800FA5VE
50 670 800 335.0 – 400.0
60 660 800 330.0 – 400.0
VAM1000FA5VE
50 870 1000 435.0 – 500.0
60 800 1000 400.0 – 500.0
VAM1500FA5VE
50 1200 1500 600.0 – 750.0
60 1200 1500 600.0 – 750.0
VAM2000FA5VE
50 1400 2000 700.0 – 1000.0
60 1400 2000 700.0 – 1000.0
