Ubiquiti NanoBridge M3 [11/12] Nbm_11
![Ubiquiti NanoBridge M3 [11/12] Nbm_11](/views2/1072787/page11/bgb.png)
Protect your networks from the most brutal
environments with Ubiquiti’s industrial-
grade shielded ethernet cable, TOUGHCable.
Increase Performance Dramatically
improve your ethernet link states, speeds,
and overall performance with Ubiquiti
TOUGHCables.
Extreme Weatherproof TOUGHCables
have been built to perform even in the
harshest weather and environments.
Eliminate ESD Attacks Protect your
networks from devastating ESD Attacks,
TOUGHCables eliminate ESD attacks and
ethernet hardware damage.
Extended Cable Support TOUGHCables
have been developed to have increased
power handling performance for extended
cable run lengths.
TOUGHCable is currently available in two
versions: Level 1 Shielding Protection and
Level 2 Shielding Protection.
Level 1 is a Category 5e (100Mbps
Ethernet Support) Outdoor Carrier Class
Shielded Cable.
Level 2 is a Category 6 (1Gbps Ethernet
Support) Outdoor Carrier Class Shielded
Cable that is also capable of providing
enhanced Category 5e performance.
Additional Information:
• 24 AWG copper conductor pairs
• ESD Drain Wire: 26 AWG integrated ESD
Drain wire to prevent ESD attacks &
damage.
• PVC outdoor rated jacket
• 0.35um foil shield
• Multi-Layered Shielding
• 1000ft (304.8m) length
Learn more:
www.ubnt.com/toughcable
ESD Attacks are overwhelmingly the leading
cause for device failures. The diagram
below illustrates the areas vulnerable to
ESD Attacks in a defenseless network.
By using a grounded Ubiquiti POE adapter
(included) along with Ubiquiti TOUGHCable
(sold separately), you can effectively
eliminate ESD Attacks.
Bulletproof your networks
11
Ubiquiti Networks, Inc. Copyright © 2011, All Rights Reserved www.ubnt.com
Misc
Unshielded
cable with
no ESD Drain
POE Adapter with
no earth ground
Ubiquiti
TOUGHCable
Ubiquiti POE
Adapter
LEVEL2
SHIELDING PROTECTION
Twisted Pair
Anti-Crosstalk Divider
ESD Drain Wire
Cable Shield
Secondary Cable Shield
Weatherproof Jacket
LEVEL1
SHIELDING PROTECTION
Twisted Pair
ESD Drain Wire
Separation
Cable Shield
Weatherproof Jacket
MAIN
ESD
OUTDOOR
ESD
LAN
ESD
Datasheet
|
