Speciﬁcations

Max Power Consumption 8 Watts5.5 Watts6.5 Watts

Antenna Gain 21.5 - 22.5 dBi18 dBi (M2)

22 dBi (M5-22)

25 dBi (M5-25)

10.6 - 11.3 dBi

System Information

Memory Information 64MB SDRAM, 8MB Flash 32MB SDRAM, 8MB Flash

Regulatory / Compliance Information

M9 M2, M5 M365M3

M9 M2, M3, M365, M5

Networking Interface 1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet 2 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet

M9, M2, M5 M3, M365

Wireless Approvals FCC Part 15.247, IC RS210 FCC Part 15.247, IC RS210, CE FCC Part 90Y-

RoHS Compliance YES

Physical / Electrical / Environmental

Weight 1565 g 1310 g 900 g

Enclosure Characteristics Outdoor UV Stabilized Plastic

Mounting Kit Pole Mounting Kit included

Power Supply 24V, 1A POE Supply included

Power Method Passive Power over Ethernet (pairs 4, 5+; 7, 8 return)

Operating Temperature -30C to 75C

Operating Humidity 5 to 95% Condensing

Shock and Vibration ETSI300-019-1.4

Processor Specs Atheros MIPS 24KC, 400MHz

Dimensions 543 x 440 x 725 mm

400 mm diameter (M2)

326 mm diameter (M5-22)

400 mm diameter (M5-25)

M2, M5

492 x 440 x 705 mm

M3, M365

Operating Frequency Summary (MHz)

2412-2462

3300-3700

M365

3650-3675

5470-5825*

902-928

* Only 5745 - 5825 MHz is supported in the USA

Datasheet

NanoBridge
