Datasheet
7
www.ubnt.com/airmax
Models
Model Frequency Gain Dish Reector
NBE-M2-400 2.4 GHz 18 dBi 400 mm
Model Frequency Gain Dish Reector
NBE-M5-400 5 GHz 25 dBi 400 mm
The NBE-M5-400 Antenna Feed has a thin gray ring around
the center of the cap to differentiate it from the NBE-M5-300
AntennaFeed.
Model Frequency Gain Dish Reector
NBE-M5-300 5 GHz 22 dBi 300 mm
Model
NBE-M2-400 NBE-M5-400 NBE-M5-300
NBE-RAD-400
ü ü
N/A
A protective radome is available as an optional accessory for the
NBE-M2-400 and NBE-M5-400.
