![Ubiquiti NanoBeam NBE-M5-300 [8/15] Specifications](/views2/1072796/page8/bg8.png)
Datasheet
8
www.ubnt.com/airmax
Specications
System Information
Model NBE-M5-19 NBE-M5-16
Processor Specs Atheros MIPS 74KC, 560 MHz Atheros MIPS 74KC, 560 MHz
Memory 64 MB DDR2, 8 MB Flash 64 MB DDR2, 8 MB Flash
Networking Interface (1) 10/100/1000 Ethernet Port (1) 10/100 Ethernet Port
Regulatory/Compliance Information
Model NBE-M5-19 NBE-M5-16
Wireless Approvals FCC, IC, CE
RoHS Compliance Yes
Physical/Electrical/Environmental
Model NBE-M5-19 NBE-M5-16
Dimensions (mm) 189 x 189 x 125 140 x 140 x 54
Weight 0.530 kg 0.320 kg
Power Supply 24V, 0.5A GigE PoE 24V, 0.5A PoE
Power Method
Passive PoE
(Pairs 4, 5+; 7, 8 Return)
Passive PoE
(Pairs 4, 5+; 7, 8 Return)
Max. Power Consumption 8 W 6 W
Gain 19 dBi 16 dBi
Wind Loading 10.2 lbf @ 125 mph 4.8 lbf @ 125 mph
Wind Survivability 125 mph
LEDs (1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs Software-Adjustable to Correspond to Custom RSSI Levels
Channel Sizes 5/8/10/20/30/40 MHz
Polarization Dual Linear
Enclosure Outdoor UV Stabilized Plastic
Mounting Pole-Mount (Kit Included), Wall-Mount
ESD/EMP Protection Air: ±24 kV, Contact:± 24 kV
Operating Temperature -40 to 70° C
Operating Humidity 5 to 95% Non-Condensing
Shock & Vibration ETSI300-019-1.4
Operating Frequency Summary (MHz)
Model NBE-M5-19 NBE-M5-16
Worldwide 5170 - 5875
USA 5725 - 5850
