Ubiquiti NanoBeam NBE-M5-16 [9/15] Specifications

Datasheet

www.ubnt.com/airmax

Specications

System Information

Model NBE-M2-400 NBE-M5-400 NBE-M5-300

Processor Specs Atheros MIPS 74KC, 560 MHz Atheros MIPS 74KC, 560 MHz Atheros MIPS 74KC, 560 MHz

Memory 64 MB DDR2, 8 MB Flash 64 MB DDR2, 8 MB Flash 64 MB DDR2, 8 MB Flash

Networking Interface (1) 10/100 EthernetPort (1) 10/100/1000 Ethernet Port (1) 10/100 EthernetPort

Regulatory/Compliance Information

Model NBE-M2-400 NBE-M5-400 NBE-M5-300

Wireless Approvals FCC, IC, CE

RoHS Compliance Yes

Physical/Electrical/Environmental

Model NBE-M2-400 NBE-M5-400 NBE-M5-300

Dimensions (mm) 420 x 420 x 289 420 x 420 x 275 325 x 325 x 256

Weight 1.795 kg 1.753 kg 1.203 kg

Power Supply 24V, 0.5A PoE 24V, 0.5A GigE PoE 24V, 0.5A PoE

Power Method

Passive PoE

(Pairs 4, 5+; 7, 8 Return)

Passive PoE

(Pairs 4, 5+; 7, 8 Return)

Passive PoE

(Pairs 4, 5+; 7, 8 Return)

Max. Power Consumption 6 W 8 W 6 W

Gain 18 dBi 25 dBi 22 dBi

Wind Loading 77 lbf @ 125 mph 77 lbf @ 125 mph 45 lbf @ 125 mph

Wind Survivability 125 mph

LEDs (1) Power, (1) LAN, (4) WLAN

Signal Strength LEDs Software-Adjustable to Correspond to Custom RSSI Levels

Channel Sizes 5/8/10/20/30/40 MHz

Polarization Dual Linear

Enclosure Outdoor UV Stabilized Plastic

Mounting Pole-Mount Kit Included

ESD/EMP Protection Air: ±24 kV, Contact:± 24 kV

Operating Temperature -40 to 70° C

Operating Humidity 5 to 95% Non-Condensing

Shock & Vibration ETSI300-019-1.4

Operating Frequency Summary (MHz)

Model NBE-M2-400 NBE-M5-400 NBE-M5-300

Worldwide

2405 - 2475

5170 - 5875

USA 5725 - 5850
