CONVENTIONAL OPERATION
■ Setting the squelch level
The squelch circuit mutes the received audio signal depending on
the signal strength.
q W
hile pushing [PTT] and [Lower],
rotate [VOL] to turn the power ON
to enter the squelch level adjust-
ment mode.
w
Push [Upper] to increase the
squelch level (tight squelch) or
[Lower] to decrease the squelch
level (loose squelch).
e
Rotate [VOL] to turn the power
OFF to fix the squelch level.
