iv
R CAUTION! NEVER hold the transceiver so that the antenna
is very close to, or touching exposed parts of the body, especially
the face or eyes, while transmitting. The transceiver will perform
best
if the microphone is 5 to 10 cm (2 to 4 in.) away from the lips
and the transceiver is vertical.
R CAUTION! NEVER operate the transceiver with a headset
or other audio accessories at high volume levels.
R CAUTION! NEVER short the terminals of the battery pack.
R CAUTION! NEVER use non-Icom battery packs/chargers to
prevent the loss of the transceiver’s good performance and warranty.
R CAUTION! NEVER
expose the transceiver to rain, snow or
any liquids. The transceiver may be damaged.
DO NOT push [PTT] when not actually desiring to transmit.
DO NOT use or place the transceiver in direct sunlight or in areas
with temperatures below –30°C (+22°F) or above +60°C (+140°F).
DO NOT modify the transceiver. The transceiver warranty does
not cover any problems caused by unauthorized modification.
MAKE SURE the flexible antenna and battery pack are securely
attached to the transceiver, and that the antenna and battery pack
are dry before attachment. Exposing the inside of the transceiver
to water will result in serious damage to the transceiver.
The use of non-Icom battery packs/chargers may impair trans-
ceiver performance and invalidate the warranty.
For U.S.A. only
CAUTION! Changes or modifications to this device, not expressly
approved by Icom Inc., could void your authority to operate this
transceiver under FCC regulations.
PRECAUTIONS
