SWIVEL BELT CLIP
6
26
6
SWIVEL BELT CLIP
■ MB-93 contents
Qty.
q Belt clip …………………………………………………………… 1
w Base clip …………………………………………………………… 1
■ To attach
q Release the battery pack if it is attached. (p. 3)
w Slide the base clip in the direction of the arrow until the base clip
is locked and makes a ‘click’ sound.
q w
e Clip the belt clip to a part of your belt. And insert the transceiver
into the belt clip until the base clip inserted fully into the groove.
r Once the transceiver is locked in place, it swivels as illustrated
below.
