Icom IC-F14/S [19/21] Options
![Icom IC-F14/S [19/21] Options](/views2/1074170/page19/bg13.png)
31
7
OPTIONS
7
30
7
OPTIONS
D BATTERY PACK
• BP-230 Li-Ion
BATTERY PACK
7.4 V/800 mAh Li-Ion battery pack, allows approx. 5.5 hours* op-
eration.
• BP-231
Li-Ion
BATTERY PACK
7.4 V/1150 mAh Li-Ion battery pack, allows approx. 8 hours* op-
eration. The same as supplied with the transceiver.
• BP-232
Li-Ion
BATTERY PACK
7.4 V/2000 mAh Li-Ion battery pack, allows approx. 14 hours* op-
eration.
*Typical operation; Tx:Rx:Stand-by duty cycle=5:5:90
D CHARGERS
• BC-119N
DESKTOP CHARGER
+ AD-106
CHARGER ADAPTER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is supplied
with the charger depending on versions. Charging time: approx. 2
hours when BP-231 is attached.
• BC-121N
MULTI
-
CHARGER
+ AD-106
CHARGER ADAPTER
(6 pcs.)
+ BC-124
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-106’s are re-
quired) simultaneously. An AC adapter should be purchased sep-
arately. Charging time: approx. 2 hours when BP-231 is attached.
• BC-160
DESKTOP CHARGER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is supplied
with the charger depending on versions. Charging time: approx. 2
hours when BP-231 is attached.
D OPTIONAL UNITS
• UT-108
DTMF DECODER UNIT
Provides pager and code squelch capabilities.
• UT-109 (#01)/UT-110 (#01)
SCRAMBLER UNITS
Non-rolling type (UT-109)/Rolling type (UT-110) voice scrambler
unit provides higher communication security.
• UT-113
MAN DOWN UNIT
Provides a measure of safety when working in a hazardous envi-
ronment, etc.
D BELT CLIPS
• MB-93
SWIVEL BELT CLIP
• MB-94
BELT CLIP
Exclusive alligator-type belt clip. The same as supplied with the
transceiver.
• MB-96*/96F
LEATHER BELT HANGER
*MB-93’s base clip is required.
D DC CABLES
• CP-17L
CIGARETTE LIGHTER CABLE
Allows charging of the battery pack through a 12 V cigarette
lighter socket. (For BC-119N)
• OPC-515L/OPC-656
DC POWER CABLES
Allows charging of the battery pack using a 13.8 V power source
instead of the AC adapter.
OPC-515L: For BC-119N
OPC-656 : For BC-121N
D OTHER OPTIONS
• SP-13
EARPHONE
Provides clear receive audio in noisy environment.
• HM-131L
SPEAKER
-
MICROPHONE
Combination speaker-microphone that provides convenient oper-
ation while hanging the transceiver from your belt.
HM-131L has a moisture proof construction.
• HS-94/HS-95/HS-97
HEADSET
+ VS-1L
VOX
/
PTT CASE
HS-94: Ear hook type HS-95: Neck-arm type
HS-97: Throat microphone
VS-1L: VOX/PTT switch box for hands-free operation, etc.
• FA-SC73US/FA-SC56VS/FA-SC57VS
STUBBY ANTENNAS
FA-SC73US: 450–490 MHz FA-SC56VS: 150–162 MHz
FA-SC57VS: 160–174 MHz
• FA-SC25U/FA-SC57U/FA-SC72U/FA-SC25V/FA-SC55V
ANTENNAS
FA-SC25U: 400–430 MHz FA-SC57U: 430–470 MHz
FA-SC72U: 470–520 MHz FA-SC25V: 136–155 MHz
FA-SC55V: 146–174 MHz
Some options may not be available in some countries. Please ask your
dealer for details.
IC-F14_F24-2.qxd 04.7.22 0:57 PM Page 30 (1,1)
