ACCESSORIES
■ Supplied accessories
The following accessories are supplied: Qty.
q Flexible antenna ……………………………………………1
w Battery pack …………………………………………………1
e Belt clip ………………………………………………………1
r Unit cover (double-sided tape)* ……………………………1
t Jack cover (with screws) ………………………………1 set
*Use the unit cover as a spare. Ask your dealer for details.
■ Accessory attachments
D Flexible antenna
Connect the supplied flexible anten-
na to the antenna connector.
CAUTION!
• NEVER HOLD by the antenna
when carrying the transceiver.
• Transmitting without an antenna
may damage the transceiver.
qw
r
e
t
