TABLE OF CONTENTS

IMPORTANT ........................................................................ i

EXPLICIT DEFINITIONS ..................................................... i

CAUTIONS ........................................................................... i

TABLE OF CONTENTS ...................................................... ii

1 PANEL DESCRIPTION ............................................. 1–5

■ Front panel ............................................................................ 1

■ Function display .................................................................... 2

■ Programmable function keys ................................................ 3

2 OPERATION ............................................................. 6–8

■ Turning power ON ................................................................. 6

■ Channel selection ................................................................. 6

■ Receiving and transmitting ................................................... 7

D Transmitting notes .......................................................... 7

D Tx code channel selection .............................................. 8

D Tx code number selection .............................................. 8

D DTMF transmission ........................................................ 8

3 CONNECTION AND MAINTENANCE .................... 9–12

■ Rear panel and connection ................................................... 9

■ Unpacking ........................................................................... 10

■ Mounting the transceiver...................................................... 11

■ Optional UT-96/UT-105 installation ..................................... 11

■ Optional OPC-617 installation ............................................. 12

■ Antenna ............................................................................... 12

■ Fuse replacement ............................................................... 12

■ Cleaning ............................................................................. 12

4 OPTIONAL SmarTrunk II™ OPERATION ........... 13–15

■ SmarTrunk II™ and conventional modes ............................ 13

■ SmarTrunk II™ operation .................................................... 13

5 OPTIONS .................................................................... 16

DO NOT use or place the transceiver in areas with tem-

peratures below –30°C or above +60°C or, in areas subject

to direct sunlight, such as the dashboard.

AVOID operate the transceiver without running the vehicle’s

engine. The vehicle’s battery will quickly run out if the trans-

ceiver is in transmission while the vehicle’s engine OFF.

AVOID placing the transceiver in excessively dusty envi-

ronments.

AVOID placing the transceiver against walls. This will ob-

struct heat dissipation.

AVOID the use of chemical agents such as benzine or al-

cohol when cleaning, as they damage the transceiver sur-

faces.

BE CAREFUL! The transceiver will become hot when

operating continuously for long periods.

For U.S.A. only

CAUTION: Changes or modifications to this transceiver, not ex-

pressly approved by Icom Inc., could void your authority to operate

this transceiver under FCC regulations.
