PANEL DESCRIPTION
■ Front panel
MICROPHONE
CONNECTOR
(P. 2)
PROGRAMMABLE
FUNCTION KEYS [P0],[P1],[P2],[P3]
(P. 3)
POWER SWITCH (P. 2)
FUNCTION DISPLAY (P. 2)
CH UP/DOWN KEYS []/[] (P. 3)
VOLUME UP/DOWN KEYS (P. 2)
