PANEL DESCRIPTION
5
TX CODE KEY
Select a transmit 5-tone code (station code) channel.
•Push and hold to changes the contents of the sta-
tion code using []/[]keys.
• Push to selects a TX 5-tone code channel using
[]/[]keys after pushing this key.
TX CODE CHANNEL UP/DOWN KEY
Push to selects a TX code channel directory.
DTMF CHANNEL SELECT KEY
Push this key to select a DTMF channel.
• Push this key, then select the desired DTMF chan-
nel using the []/[]keys.
Push and hold this key to transmit the selected
DTMF code.
NOTE: DTMF channels 6 and 7 are used for ID
code and emergency code respectively, depend-
ing on your system set up.
Ask your System Operator or Dealer about DTMF
channels 6 and 7 before using these.
C. TONE CHANNEL ENTER KEY
Push this key then input a continuous tone memory
channel number via the keypad to change the tone
frequency.
TX CH
CODE
DTMF
ID MR
ID MEMORY READ KEY
Recalls detected ID codes.
• Push this key, then push []/[]for selection.
• Up to 5 ID's are memorized.
Push and hold this key to erase all memorized IDs.
LIGHT
Push to select the backlight condition.
ON :Turns ON the backlight continuously.
OFF :Turns OFF the backlight.
AUTO :Turns ON/OFF depending on the ACC
socket pin 1 voltage.
ON: Low (0 V) OFF: High (12 V)
ATTENUATOR
Push to turn the attenuator function ON/OFF.
NOTE: The attenuator function protects desired
signals from distorting when excessively strong
signals, such as broadcast, pager signals, etc.
are nearby.
TRUNKING GROUP SWITCH
Push to select the Trunking group.
LITE
ATT
TONE
GRP
