Icom IC-PCR100 [5/44] Installation
![Icom IC-PCR100 [5/44] Installation](/views2/1074683/page5/bg5.png)
1
1
INSTALLATION
■ Hardware installation
Refer to the diagram below for connections.
Ground
Supplied antenna
to an AC adapter
to an
RS-232C port
External speaker
Personal computer
