Designed for work with cut-off wheels, diamond cut-
off wheels.
Install as described under "Safety guard for
grinding" (chapter 6.2).
D Hand guard for sanding and wire brushing
operations
Designed for work with support plates, sanding
pads, wire brushes.
Install hand guard under the additional side-
mounted handle.
EAdjusting nut (15)
F Clamping nut (tool-free) (2)
G Dust filter (12)
For a complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out
by qualified electricians ONLY!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. For
addresses see www.metabo.com.
You can download a list of spare parts from
www.metabo.com.
The sanding dust generated may contain
hazardous materials: do not dispose of with the
household waste, but at a special collection point
for hazardous waste.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Battery packs must not be disposed of with regular
waste. Please return faulty or used battery packs to
your Metabo dealer.
Do not throw battery packs into water.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline 2002/
96/EC on used electronic and electric equipment
and its implementation in national legal systems,
used power tools must be collected separately and
handed in for environmentally compatible recycling.
Before disposal, discharge the battery pack in the
power tool. Prevent the contacts from short-
circuiting (e. g. by protecting them with adhesive
tape).
Explanation of details on page 2 . Subject to
changes serving technical progress.
U =Voltage of battery pack
D
max
=max. diameter of accessory
t
max,1
=max. permitted thickness of clamping
shank on accessory when using clamping
nut (15)
t
max,2
=max. permitted thickness of clamping
shank on accessory when using
"Quick"clamping nut
(2)
t
max,3
=Roughing disc/Parting disc:
max. permitted thickness of
accessory
M=Spindle thread
l=Length of the grinding spindle
n =No-load speed (maximum speed)
P
1
=Nominal power input
P
2
=Power output
m =Weight without mains cable
Measured values determined in conformity with
EN 60745.
Direct current
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Emission values
These values make it possible to assess the
emissions from the power tool and to compare
different power tools. Depending on the operating
conditions, the condition of the power tool or the
accessories, the actual load may be higher or lower.
For assessment purposes, please allow for breaks
and periods when the load is lower. Based on the
adjusted estimates, arrange protective measures
for the user e.g. organisational measures.
Vibration total value
(vector sum of three directions)
determined in accordance with EN 60745:
a
h, SG
=Vibration emission value (sanding
surfaces)
a
h, DS
=Vibration emission value (sanding with
sanding pad)
K
h,SG/DS
=Uncertainty (vibration)
Typical A-effective perceived sound levels
:
L
pA
=Sound pressure level
L
WA
=Acoustic power level
K
pA
, K
WA
= Uncertainty
During operation the noise level can exceed
80 dB(A).
Wear ear protectors!
12. Repairs
13. Environmental Protection
14. Technical Specifications
