Zigmund & Shtain K 376.51 W [18/52] Use and maintenance

- 18 -

omnipolar switch with 3 mm minimum opening between con-

tacts must be fitted between the appliance and the electricity

supply in compliance with the load and current regulations.

- The connection to the mains is carried out as follows:

BROWN = L line

BLUE = N neutral.

•The minimum distance between the support surfaces of

the cooking pots on the cooker top and the lowest part of

the cooker hood must be at least 65 cm. If a connection tube

composed of two parts is used, the upper part must be pla-

ced outside the lower part. Do not connect the cooker hood

exhaust to the same conductor used to circulate hot air or for

evacuating fumes from other appliances generated by other

than an electrical source.

- In the case of assembly of the appliance in the suction version

prepare the hole for evacuation of the air.

•We recommend the use of an air exhaust tube which has the

same diameter as the air exhaust outlet hole. If a pipe with a

smaller diameter is used, the efficiency of the product may be

reduced and its operation may become noisier.

•Installation:

The following instruction should be followed to carry out the

correct installation of the cooker hood.

1. Mounting of the cooker hood on the lower side of the

cupboard.

2. Choosing the version (extractor, Fig.1A, or filter, Fig.1B).

•Fixingthehoodtothelowerpartofthewallcabinet:

This type of appliance must be fitted inside a cabinet or inside

another type of support structure. The overall measurements

of the cooker hood are given in figure 2. Before proceeding

with cooker hood installation, remove grille D by pressing the

two side buttons A, as shown in figure 3. Fix the appliance in

place using 8 screws (not supplied) which are suited to the

type of cabinet. To install the cooker hood correctly, first fit

the 4 screws A and then the 4 screws B, in accordance with

the diagram in figure 4. After fixing the cooker hood to the

lower part of the cabinet, place grille D (Fig.4) back in the

correct position. During this procedure, make sure that grille

D is fastened properly.

•Extractionthroughanoutsidewall:

The appliance expels the fumes through an outside wall or

a duct. It is necessary to buy a telescopic pipe in accordance

with the standards in use (inflammable) and connect it to

flange H (Fig.1A).

•Recirculation:

To transform an extractor hood version into a filter hood

version, contact your appliance dealer and ask for active

charcoal filters. The filters should be fitted to the extraction

assembly inside the hood, by centring them and rotating them

90 degrees, until they click into place (Fig.6). To perform this

operation, first remove grille D (Fig.3). The air is released back

into the room through air exhaust piping which passes through

the cabinet and is connected to flange H (Fig.1B).

USE AND MAINTENANCE

•We recommend that the cooker hood is switched on before

any food is cooked. We also recommend that the appliance is

left running for 15 minutes after the food is cooked, in order

to thoroughly eliminate all contaminated air. The effective

performance of the cooker hood depends on constant main-

tenance; the anti-grease filter and the active carbon filter both

require special attention.

•Theanti-greasefilter is responsible retaining the grease

particles suspended in the air, therefore it is subject to clogging

with variable frequency according to the use of the appliance.

- To prevent the danger of possible fires, at least every 2

months one must wash the anti-grease filters by hand using

non-abrasive neutral liquid detergents or in the dishwasher

at low temperatures and on short cycles.

- In the event that acrylic anti-grease filters are used, hand-

wash every 2 months, using neutral non-abrasive liquid

detergents and replace them after every 6 washes.

- After a few washes, colour alterations may occur. This does

not give the right to claim their replacement.

•Theactivecarbonfilters are used to purify the air that is

sent back into the room and its function is to mitigate the

unpleasant odours produced by cooking.

- The non-regenerable active carbon filters must be replaced

at least every 4 months. The saturation of the active charcoal

depends on the more or less prolonged use of the appliance,

on the type of kitchen and on the frequency with which anti-

grease filter is cleaned.

•Beforeremountingtheanti-greasefiltersandtherege-

nerable active charcoal filters it is important that they are

completely dry.

•Cleanthehoodfrequently,bothinternallyandexternally,

using a cloth dampened with water or non-abrasive neutral

liquid detergents.

•The lighting .system is designed for use during cooking

and not for the prolonged general lighting of the room. The

prolonged use of the lighting system significantly decreases

the average duration of the bulbs.

•Attention: the non compliance with the hood cleaning

warnings and with the replacement and cleaning of the filters

entails risk of fires. One therefore recommends keeping to the

suggested instructions.

•Replacingthealuminiumpanels:

To replace the aluminium panels, simply pull handle A as

shown in Fig.4B.

•Replacingtheacrylicormetalpanels:

To replace the acrylic or metal panels, first remove grille D by

pressing the two side buttons A, as shown in figure 3. Remove

the two filter clips B (Fig.5) and the acrylic or metal panel C. To

reassemble the part, simply perform the procedure in reverse.

•Replacinghalogenlightbulbs(Fig.7):

To replace the halogen lamps B, from the inside of the cooker

hood press downwards with two fingers as shown in Fig.7.

Replace the bulbs with new ones of the same type.

•Replacingthehalogen/incandescentlamps(Fig.12):

Only use lamps of the same type and Wattage installed on

the device.

•Commands(Fig.8):

Push-button A = On/off lights switch.

Push-button B = On/off cooker hood switch. The appliance

switches on at speed level 1, If the cooker hood is on depress

the push-button for 2 sec. to switch off the cooker hood. If

the cooker hood is at speed level 1 it will not be necessary

to depress the push-button to switch the cooker hood off.

Decreases the motor speed.

Display C = Indicates the motor speed level selected and

activates the timer.

Push-button D = Switches on the cooker hood. Increases the

Zigmund & Shtain K 376.51 W [18/52] Use and maintenance
