Candy BCBF 192 F [25/147] Care and cleaning
![Candy BCBF 192 F [25/147] Care and cleaning](/views2/1764418/page25/bg19.png)
25
7. Fresh meat and fish
8. Fruit and vegetables
The fridge shelves can be moved
according to the storage requirements
within the fridge section.
To move the shelf, lift up the rear
section and then pull it outwards. To
replace, slide the shelf back into the slot,
and then lower the rear section.
The wine racks can be deployed or
withdrawn as desired.
The most energy-saving configuration
requires drawers, food box and
shelves to be positioned in the
product, please refer to the above
pictures
Control Panel
Fig.3
A. Refrigerator temperature adjustment
sensor
This button is used to adjust the
temperature within the fridge. Press this
sensor once to activate adjustment, and
then as many times as necessary until
the desired level is selected. The settings
range from 1 to 6 with 1 being the
warmest and 6 being the coldest.
Please note: Where possible, avoid
having the temperature setting on 6 all
of the time. This well help to alleviate
strain on the compressor and
refrigeration system.
B. Refrigerator temperature setting
display
This display will illuminate the current
temperature setting. Adjusting the
temperature will cycle through this
display.
Please note: You do not use numbers 1
to 6 to change the temperature. Instead,
use the refrigerator temperature
adjustment sensor (A).
C. Power button
Use this sensor to switch the appliance
on and off (standby mode). The sensor
will be illuminated when the appliance is
off.
Care and cleaning
Always disconnect the appliance from
the power supply before any cleaning or
maintenance.
The fridge and freezer sections should be
cleaned using a solution of bicarbonate
of soda and lukewarm
water. Do not use abrasive products or
detergents. After washing, rinse and dry
thoroughly.
Clean the shelves and balconies
separately by hand with a mild solution
of washing up liquid and water. Do not
put them in the dishwasher.
Position Conditions
1-2 Summer or ambient
temperature between 25-
35 °C
3-4 Spring, autumn or ambient
temperature between 15-
25 °C
5-6
Winter, or ambient
temperature between 5-15
°C
