3029
Supports
simultaneous
running of the
triple and double
twin multi
operations.
T
riple
Multi Operation
Double twin
Multi Operation
To achieve increased durability by improved resistance
to salt corrosion and atmospheric pollution, coated PE
fins (with special acryl pretreatment) are used for the
heat exchanger of the outdoor unit.
Durable
Quiet operation
Small, lightweight, and easy-to-install outdoor unit.
Compact
51
dB(A)
FDY06KA
Sound level
Highly durable outdoor unit has PE fins for improved
resistance to salt corrosion and atmospheric pollution.
Durable
Many options are available for use with large-scale and
advanced-function centrally controlled systems
Central control
Quiet operation
S uc tion chamber
Air filter
[Duct c onnec tion]
To prevent increased operation sound, avoid installing the air suction grille
directly below the suction chamber.
FDYB50KA
FDY06KA
38
dB(A)
FDYB50KA
LOW
Sound level
Ideal for quiet, beautiful living spaces
Suitable for condominiums and apartments, houses and hotels
Recommended for spacious and large-volume areas because of its flexible installation
Suitable for large stores, factories, and other large areas, and for use with housing
ducts in homes
Digital remote controller Remote controller
High
See pages 31–32 for details of the Multi Series.
Guide Line up
P. 3–10
Outdoor units
P. 33–34
Options
P. 59
Outer dimension drawings
P. 64
Remote controllers
P. 35–36
Standard specifications
P. 42, 52, 56
Guide
Line up
P. 3–4, 7–8
Outdoor units
P. 33–34
Options
P. 59
Outer dimension drawings
P. 65–67
Remote controllers
P. 35–36
Standard specifications
P. 44, 45, 53
Simultaneous air conditioning of two rooms and ventilation grille (ventilation opening)
Ventilation grille
Door-installed
ventilation grille
Ventilation grille
Wall-installed
ventilation grille
Under-door cutout
Under-door cutout
When air conditioning two rooms
simultaneously, the air discharged into each
room must be circulated back to the air
conditioner. To achieve this, a ventilation
duct should be installed for each room or one
of the indicate ventilation grilles should be
installed on the partitioning wall or under the
door between the rooms.
Ventilates air through
the partitioning wall.
(S ee right)
Partitioning wall
Note: The under-door cutout method should be used only when there is a small volume of airflow.
Cooling only
Heat pump
KRC47-2A
KRC47-4A
KRC47-1A
Remote controller
Cooling only
KRC47-3A
Wired LCD remote controller Wireless LCD remote controller
Wireless remote
controller and
signal rec eiver unit
are s old as a set.
Note: R emote c ontroller cable not
included. C ables must be
procured loc ally.
Accessory required for indoor unit (option)
BRC1C61
BRC4C62
Heat pump
Wired LCD remote controller Wireless LCD remote controller
Wireless remote
controller and
signal rec eiver unit
are s old as a set.
Note: R emote c ontroller cable not
included. C ables must be
procured loc ally.
Accessory required for indoor unit (option)
BRC1C61
BRC4C62
DUCT CONNECTION
LOW STATIC PRESSURE TYPE
FDBG/FDYB
FDBG25AVE
–
71AVECooling only
FDYB35KAVE–71KAVE
Heat pump
DUCT CONNECTION
HIGH STATIC PRESSURE TYPE
FD
(
Y
)
FD03KY1–20KY1Cooling only
FDY06KAY1–20KAY1Heat pump
*2 *3
*3
*2*4 *4*1
Features (Features are explained on P. 37–38.)
Feature
Model
Heat pump
Cooling only
*
1
Applicable to R Y140LU outdoor units (for temp. down to – 5°C ) and R Y200LU– R Y250LU outdoor units (for temp. down to – 0°C )
*
2
Applicable to R (Y)140LU outdoor units
*
3
R equired to c hange the pulley
*
4
FDY06-10 only
Comfort
Work & Servicing
Control features Others
Hot s tart
Timer selector
Pre c harged for
up to 30 m
Low gas pres s ure
detec tion
E mergenc y operation
S elf-diagnos is function
C ontrol by 2 remote
controllers
Auto-res tart
Adjus table external
static pres sure
G roup c ontrol by 1 remote
controller
E xternal c ommand
control
C entral remote
control
Interloc k c ontrol
PE fin
Automatic c ool /heat
change -over
Year-round c ooling
applicable
Comfort
Work & Servicing
Control features Others
*2*2*1
Features (Features are explained on P. 37–38.)
Feature
Model
Heat pump
Cooling only
*
1
Applicable to R Y71LU outdoor units (for temp. down to – 5°C )
and R Y200LU– R Y250LU outdoor units (for temp. down to – 0°C )
*
2
Applicable to R Y71LU outdoor units
S witc hable fan speed
Programme "Dry"
Hot s tart
Timer selector
Pre c harged for
up to 30 m
Low gas pres s ure
detec tion
E mergenc y operation
S elf-diagnos is function
C ontrol by 2 remote
controllers
Auto-res tart
Adjus table external
static pres sure
G roup c ontrol by 1 remote
controller
E xternal c ommand
control
C entral remote
control
Interloc k c ontrol
PE fin
Triple and double twin
multi operation
Automatic c ool /heat
change -over
Year-round c ooling
applicable
(220V)
Signal receiver unit
(Separate type)
Signal receiver unit
(Separate type)
Note : Anechoic c hamber c onvers ion value,
measured acc ording to J IS parameters and c riteria.
FDBG60AVE
42 39
Indoor unit High Low
dB(A)
