CEILING SUSPENDED TYPE
16
39
/
35
dB(A)
FHY71B
High Low
Sound level
Upgrade to a quiet and
compact system.
15
Guide Line up
P. 3–10
Outdoor units
P. 33–34
Options
P. 57
Outer dimension drawings
P. 60
Remote controllers
P. 35–36
Standard specifications
P. 39, 47, 49, 55
38 33
50B
60B
38 33
Quiet operationSpreads comfortable air throughout the room
Installation flexibility for freedom of design
Wide air discharge openings
produce a spreading 100° airflow
Auto-swing for comfort in
all directions
Reduced edge space,
more flexible installation
Uniform height and depth. Compact
design for small-capacity models to
meet tighter dimensional constraints.
All wiring and internal servicing
done from below the unit
Drain pump kit (option) can be
easily incorporated
Installable
on ceilings
3.5 m high
Switchable fan speed: High/Low
Programme "Dry"
Indoor unit High Low
35B
37 32
71B
39 35
100B
42 37
125B
44 39
*Water used in the tes t-run c an now be drained from the air
discharge opening rather than from the side as was formerly
the cas e.
Weight of all models reduced (down 10%
compared with previous models). Trans fer and
installation work is less arduous .
Improved-oil resistant grille
Oil-resistant plastic is used for the air
discharge grille. This improves
durability in restaurants and other
similar environments.
Absence of bristles minimises clinging
dirt and simplifies
cleaning.
It is easy to wipe dirt off the flat
side and lower surfaces of the unit.
The unit fits more snugly into tight
spaces.
Pipes more easily rigged, too
Plastic panels are used to conceal
piping holes. Holes can be easily
punched out without requiring special
tools.
Drain pipe connection can be done
inside the unit. Refrigerant and drain
pipe outlets are at the same opening.
For all maintenance tasks,
access is from bottom
surface.
Easier to maintain
Long-life filter lasts about 1 year *
Maintenance not required
* For dust concentration of 0.15 mg/m
3
Note: Intended for use in salons, dining rooms, and
ordinary sales floors, this specification is not
suitable for kitchens or other harsh environments.
1,160
mm
(
1,300
mm
)
30
mm
(
60
mm
)
30
mm
(
60
mm
)
1,220
mm
(
1,420
mm
)
Dimens ions in brackets are for previous model.
For 71B indoor unit
Two time settings (2500 hrs and 1250 hrs) are available
to match the installation environment. Maintenance time
warning is displayed on the remote controller (filter sign).
Low gas pressure detection
Non-dew flap without bristles
Easy-clean, flat surfaces
100°
195
100B 125B
960 1,160 1,400 1,590
680
(mm)
Drain pump kit (built inside main unit)
Two selectable temperature-sensors
Both indoor unit and wired remote controller
(option) contain temperature-sensors. Tem-
perature sensing can be set at the unit or, to
further improve comfort level, closer to the
target area at the wired remote control.
Sound operation has been reduced on the
exposed ceiling suspended type unit.
Height
Indoor unit
Width
Depth
Twin Multi Operation
Triple Multi Operation
DoubleTwin Multi Operation
See pages 31–32 for details of the Multi Series.
Supports simultaneous running of the twin,
triple and double twin multi operation.
Uses quiet stream fan
and other quiet
technologies.
Sound damper
Turbulent flow
is produced
Non-dew flap
Straightening
vane
Quiet
stream fan
*
Temperature-s ensor on indoor unit mus t be used when
the air c onditioner is c ontrolled from another room.
**Wireless remote c ontroller does not have a temperature-
sens or.
35B/50B 60B/71B
600 mm
Dehumidification is microprocessor con-
trolled to prevent abrupt and uncomfort-
able changes in air temperature.
BRC7EA66
Wired LCD remote controller Wireless LCD remote controller
A s ignal receiver mus t be
added to the indoor unit.
Wireless remote
controller and
signal receiver unit
are sold as a s et.
Note: R emote c ontroller c able not
included. C ables mus t be
procured locally.
Accessory required for indoor unit (option)
BRC1C61
Cooling only
BRC7E63W
Heat pump
CEILING SUSPENDED
TYPE
FH
(
Y
)
FH(Y)35BVE–125BVECooling only
FHY35BVE–125BVEHeat pump
Heat pump
Cooling only
*6*2 *5
*6
*6
*6*5*2
*4
*3
Mould
prevention
Feature
Features (Features are explained on P. 37–38.)
*
1
Ins tallable on max. 3.5 m high ceiling
*
2
Applicable when wired remote controller is us ed
*
3
Applicable to R 71L U– R 140LU outdoor units (for temp. down to – 15°C )
(An option is required.)
*
4
Applicable to R Y71L U– R Y140LU outdoor units (for temp. down to – 5°C)
and RY200LU– R Y250LU outdoor units (for temp. down to – 0°C )
*
5
Optional available
*
6
Applicable to R (Y)71LU– 140LU outdoor units
Pre c harged for
up to 30 m
Long-life filter
Mould resistant treatment
for filter
Filter s ign
Low gas pres s ure
detec tion
E mergency operation
S elf-diagnos is func tion
C ontrol by 2 remote
controllers
Auto-res tart
C ontrol by 1 remote
controller
E xternal c ommand
control
C entral remote c ontrol
Twin / triple / double twin
multi operation
PE fin
Interloc k c ontrol
Model
Drain pump mechanism
S witchable fan s peed
Auto s wing
Programme "Dry"
High ceiling
application *1
Year-round cooling
applicable
Timer s elector
Draft prevention function
Hot s tart
Mould-proofing
drain pan
Two s electable
temperature-sens ors
Auto-c ooling/heating
change-over
Comfort Work & Servicing Control features Others
Signal receiver unit
(Installed type)
Note : Anec hoic c hamber c onversion value,
measured ac c ording to J IS parameters and
dB(A)
