Korting OKB9113CFX [42/44] B b a a

Figure 9.

Removing the door with vertical frame.

The door can be disassembled to enable the glass to be cleaned, it is possible to take off the upper part by

using a coin, please see the figure 10.1 below.

Figure 10.1

For 2-glass version:

Once having extracted the upper part, slide out the glass, please see the figure 10.2 below, and re-install it

by reversing the procedure:

For 3-glass version:

Once having extracted the upper part, slide out the external glass first (the one facing the oven cavity), and

then the other glasses, please see the figure 10.3 below, and re-install them by reversing the procedure:

Figure 10.2 Figure 10.3

B B
