For Your Safety
These instructions have been drawn up for your safety and that of others. You are
therefore requested to read them carefully before installing and using the appliance.
Keep this instruction manual for future reference as necessary. If the appliance is sold
or moved, make sure that the manual is handed over to the new user.
Installation
• Installation of the appliance and its connection to the electrical mains must only
be carried out by QUALIFIED STAFF.Before any procedure, it is important to
check that the appliance is DISCONNECTED from the electrical mains.
• It is risky to modify or attempt to modify the characteristics of this product.
• After removing the appliance from the packaging, make sure that it is undamaged
and that the electrical lead is in perfect condition.Otherwise, contact your dealer
before putting the appliance into operation.
• The Manufacturer declines all responsibility in case of failure to comply with the
accident prevention regulations.
• Make sure that air is able to circulate freely around the appliance.Poor ventilation
produces a shortage of oxygen.
• Make sure that the appliance is supplied with the type of gas indicated on the relative
sticker next to the mains gas connection pipe.
• Use of a gas cooking appliance produces heat and moisture in the room in
which it is installed.Ensure that the room is well ventilated by keeping the air
intakes open and in good working order or by installing an extractor hood
with discharge pipe.
• If the appliance is used intensively for a long time the effectiveness of the
ventilation will have to be increased, for example by opening a window or
increasing the power of any electric extractor fan.
During use
• This product is designed to cook foods inside ordinary homes and for non-professional
purposes.It should not be used for any other purpose.
• After using the appliance, make sure that all controls are in "CLOSED" or "OFF"
position.
• If you use an electrical socket close to this appliance, take care that the cables of
the appliances you are using do not touch it and are far enough away from the hot
parts of this appliance.
Accident Prevention
• The appliance must not be used be people (including children) with limited physical,
sensory or mental abilities, or without experience or expertise, unless they have
received instructions for using it from those responsible for their safety.
Young children should be supervised to ensure they not play with the appliance.
• The exposed parts of this appliance heat up during cooking and remain hot for some
time even after it is switched off. Keep children well away until the appliance has
cooled down.
3
