Korting HG650CTRN [9/30] By pass diameters

Technical Data

Burner Ø of tap by-pass in 100ths of a mm

Auxiliary 27

Semi-rapid 31

Rapid 42

Triple flame 57

Triple f. Dual

(total core)

T. Corona Dual

(internal core)

MAXIMUM MINIMUM G 20 G30/G31

BURNER OUTPUT OUTPUT 20 mbar 28-30/37 mbar

TYPE

kW kW Nozle Cons. Nozle Cons.

marking m

/h marking g/h

100/mm 100/mm

Auxiliary burn. 1,00 0,33 72 0,095 50 73

Semi-rapid burn. 1,75 0,48 97 0,167 65 128

Rapid burn. 3,00 0,75 115 0,286 85 219

Triple flame burn. 3,80 1,35 135 0,363 98 277

Triple f. burn.Dual 4,20 1,45 66 306

Triple f. burn.Dual 4,50 1,45 105 0,429

Triple f. burn.Dual 1,00 0,33 71 0,095 50 73

(internal core)

By-pass diameters

Burner power in kW:

Small auxiliary burner 1,00

Medium semi-rapid burner 1,75

Large rapid burner 3,00

Triple flame burner 3.80

Triple flame burner dual 4,20 (G30/G31)

Triple flame burner dual 4,50 (G20)

Gas intake connection G 1/2”

Electricity supply 220 / 230 V ~ 50 Hz

Class of appliance: 3
