PRIME/Pro/ProArt/TUF GAMING B550 / A520 Series BIOS Manual

VDDCR CPU Power Duty Control

This item allows you to set the duty cycle of each VRM phase based upon current and/

or temperature.

[T.Probe] Sets the buck controller to balance VRM FET temperatures.

[Extreme] Sets the buck controller to balance per phase current.

DO NOT remove the thermal module. The thermal conditions should be monitored.

VDDCR SOC Load Line Calibration

Conguration options: [Auto] [Level 1] – [Level 5]

VDDCR SOC Current Capability

Conguration options: [100%] [110%] [120%] [130%]

VDDCR SOC Switching Frequency

Use the <+> or <-> to adjust the value. The values range from 200 to 350 with an

interval of 50.

VDDCR SOC Power Phase Control

Conguration options: [Optimized] [Extreme] [Manual]

The following item appears only when the VDDCR SOC Power Phase Control is set to

[Manual].

Manual Adjustment

This item allows you to set the response time, selecting [Regular] will

result in longer reaction times.

Conguration options: [Regular] [Medium] [Fast] [Ultra Fast]

VDDCR CPU Voltage

Conguration options: [Auto] [Manual] [Offset mode]

The following item appears only when you set the VDDCR CPU Voltage to [Manual].

VDDCR CPU Voltage Override

Conguration options: [Auto] [0.750] - [2.000]

The following items appear only when you set the VDDCR CPU Voltage to [Offset mode].

VDDCR CPU Offset Mode Sign

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

VDDCR CPU Offset Voltage

Conguration options: [Auto] [-0.00625] - [+0.50000]

VDDCR SOC Voltage

Conguration options: [Auto] [Manual] [Offset mode]

The following item appears only when you set the VDDCR SOC Voltage to [Manual].
