viii
ROG STRIX B550-F GAMING (WI-FI) specifications
summary
Internal I/O Connectors
Miscellaneous
1 x AURA Addressable Gen 2 header
2 x AURA RGB headers
1 x Clear CMOS header
1 x Front Panel Audio header (AAFP)
1 x 20-3 pin System Panel header
1 x Thermal sensor header
1 x Thunderbolt header
Special Features
ASUS Q-Design
- ASUS Q-DIMM
- ASUS Q-LED (DRAM [yellow],CPU [red], VGA [white], Boot Device
[yellow green)
- ASUS Q-Slot
ASUS Thermal Solution
- Aluminum M.2 heatsink design
ASUS EZ DIY
- BIOS Flashback™ button
- BIOS FlashBack™ LED
- Clear CMOS header
- ProCool
- Pre-mounted I/O shield
- SafeSlot
AURA Sync
- Standard RGB headers
- Addressable Gen 2 RGB header
Software Features
ROG Exclusive Software
- RAMCache III
- ROG CPU-Z
- GameFirst VI
- Sonic Studio III + Sonic Studio Virtual Mixer
- Sonic Radar III
- DTS
®
Sound Unbound
- Overwolf
- Anti-virus software
ASUS Exclusive Software Features
Armoury Crate
- Aura Creator
- Aura Sync
- AI Noise Cancelling Microphone
(continued on the next page)
