ROG STRIX B360-G GAMING specifications summary
Back I/O Ports
1 x PS/2 keyboard/mouse combo port
2 x USB 2.0 ports
1 x DVI port
1 x HDMI 1.4b port
2 x USB 3.1 Gen 2 ports (2 x Type-A [Red])
1 x LAN (RJ45) port
2 x USB 3.1 Gen 1 ports
1 x Optical S/PDIF out
5 x Gold-plated audio jacks
Internal I/O
Ports
1 x AAFP connector
1 x 4-pin RGB Header
1 x USB 3.1 Gen 1 connector supports additional 2 x USB 3.1 Gen 1 ports
2 x USB 2.0 connectors supports additional 4 x USB 2.0 ports
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support
(SATA & PCIE 3.0 x 2 mode)
1 x M.2 Socket 3 with M key, type 2242/2260/2280storage devices support
(PCIE 3.0 x 4 mode)
1 x TPM connector
1 x COM port connector
6 x SATA 6Gb/s connectors
1 x AIO_Pump connector
1 x CPU Fan connector
1 x Chassis Fan connector
1 x 8-pin EATX 12 V Power connector
1 x 24-pin EATX Power connector
1 x Clear CMOS jumper
1 x System panel connector
BIOS
1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI
6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan
Control, F3 My Favorites, Last Modied log, F12 PrintScreen and ASUS
DRAM SPD (Serial Presence Detect) memory information, ASUS Secure
Erase, ASUS User Prole, F4 AURA ON/OFF, F9 Search
Manageability
WOL, WOR, PXE
Software
Drivers
EZ Update
Anti-virus software (OEM version)
ASUS Utilities
Operating
system support
Windows
®
10 64-bit
Form factor
Micro ATX Form Factor 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
Specications are subject to change without notice. Please refer to the ASUS website for
the latest specications.
