Asus ROG STRIX B360-G GAMING [17/76] System memory

ROG STRIX B360-G GAMING

1-5

Chapter 1

Recommended memory configurations

1.1.4 System memory

ThemotherboardcomeswithfourDDR4(DoubleDataRate4)QuadInlineMemoryModules

(DIMM)slots.

ADDR4moduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.DONOT

installaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.

TherecommendedmemoryDIMMslotsaremarkedwithanasterix(*).
