ROG STRIX B360-G GAMING specifications summary
CPU
Intel
®
Socket 1151 for 8th generation Core Processors
Supports Intel
®
Turbo Boost Technology 2.0*
* Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types
Chipset
Intel
®
B360 Chipset
Memory
4 x DIMM, max. 64GB DDR4 2666 / 2400 / 2133 MHz Non-ECC, Un-
buffered Memory*
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Due to Intel
®
chipset limitation, DDR4 2666MHz memory frequency is only
supported by 8th Generation Intel
®
6-core processors. Higher memory modules
will run at the maximum transfer rate of DDR4 2666MHz.
Graphics
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support : HDMI/DVI ports
- Supports DisplayPort 1.2 with max. resolution 4096 x 2304 @ 60Hz
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 30Hz
Maximum shared memory of 1024MB
Multi-GPU
Support
Supports AMD
®
2-Way CrossFireX™ Technology
Expansion slots
1x PCIe 3.0 x16 Safeslot
1 x PCIe 3.0 x 16 slot (max. at x4 mode)
2 x PCIe 3.0 x1 slots
Storage
Intel
®
B360 Chipset
- 6 x SATA 6Gb/s ports
Intel
®
B360 Chipset
- 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices
support (SATA & PCIE 3.0 x 2 mode)
- 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices
support (PCIE 3.0 x 4 mode)*
- Ready for Intel
®
Optane Memory*
* Before using Intel
®
Optane memory modules, ensure that you have updated your
motherboard drivers and BIOS to the latest version from ASUS support website.
LAN
1 x Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
(continued on the next page)
