Asus ROG STRIX B360-G GAMING [25/76] Chapter 1

ROG STRIX B360-G GAMING

1-13

Chapter 1

7. USB 3.1 Gen 1 connectors (20-1 pin U31G1_56)

TheseconnectorsallowyoutoconnectaUSB3.1Gen1moduleforadditionalUSB

3.1Gen1frontorrearpanelports.WithaninstalledUSB3.1Gen1module,youcan

enjoyallthebenetsofUSB3.1Gen1includingfasterdatatransferspeedsofupto

5Gbps,fasterchargingtimeforUSB-chargeabledevices,optimizedpowerefciency,

andbackwardcompatibilitywithUSB2.0.

DONOTconnecta1394cabletotheUSBconnectors.Doingsowilldamagethe

motherboard!

TheUSB2.0moduleispurchasedseparately.

6. USB 2.0 connector (10-1 pin USB910, USB1114)

ThisconnectorisforUSB2.0ports.ConnecttheUSBmodulecabletothese

connectors,theninstallthemoduletoaslotopeningatthebackofthesystemchassis.

ThisUSBconnectorcomplieswithUSB2.0specicationthatsupportsupto480Mb/s

connectionspeed.

TheUSB3.1Gen1moduleispurchasedseparately.
