Daikin 4MXS68F2V1B [393/501] Detach the outdoor temperature thermistor
![Daikin 4MXS68F2V1B [393/501] Detach the outdoor temperature thermistor](/views2/1761937/page393/bg189.png)
SiBE121021_C Outdoor Unit - 50~75 Class
Removal Procedure 381
3
Remove the 2 screws
of the wiring fixture.
4
Detach the outdoor
temperature thermistor.
5
Remove the screw on
the right side of the
electrical box.
Step
Procedure Points
(R11181)
Wiring
fixture
