Outdoor Unit - 80/90 Class SiBE121021_C
426 Removal Procedure
4. Remove the terminal
board.
1
Remove the screw.
2
Unfasten the hook.
3
Remove the terminal
board.
Step
Procedure Points
(R10411)
Terminal board
(R10412)
(R10413)
