Asus RS700A-E11-RS12U [12/186] System package contents

Chapter 1: Product Introduction

1-2

If any of the above items is damaged or missing, contact your retailer.

1.1 System package contents

Check your system package for the following items.

Model Name

RS700A-E11-RS12U

Chassis

ASUS R12F 1U Rackmount Chassis

Motherboard

ASUS KMPP-D32 Server Board

Component

1 x 1200W 80PLUS Platinum Power Supply or 1600W 80PLUS Platinum Power

Supply

1 x 2.5-inch Storage Device Backplane

12 x 2.5-inch Storage Device Trays or Dummy Trays

1 x Front Panel Board

2 x Riser Card

8 x System Fans (40 mm x 40 mm x 56 mm)

Accessories

1 x AMD EPYC™ Support DVD

1 x Bag of Screws

2 x CPU Heatsink

2 x AC Power Cable

Optional Items

1 x 1200W 80PLUS Platinum Power Supply or 1600W 80PLUS Platinum Power

Supply (Second PSU)

1 x Friction Rail Kit
