5-56
Chapter 5: BIOS Setup
5.12.2 View Smbios Event Log
Press <Enter> to view all smbios event logs.
Enabling/Disabling Options
Smbios Event Log [Enabled]
Change this to enable or disable all features of Smbios Event Logging during boot.
Configuration options: [Disabled] [Enabled]
The following items appear only when Smbios Event Log is set to [Enabled].
Erasing Settings
Erase Event Log [No]
Choose options for erasing Smbios Event Log. Erasing is done prior to any logging activation
during reset.
Configuration options: [No] [Yes, Next reset] [Yes, Every reset]
Smbios Event Log Standard Settings
Log System Boot Event [Disabled]
This option allows you to enable or disable logging System boot event.
Configuration options: [Disabled] [Enabled]
MECI [1]
The Multiple Event Count Increment is the occurrences of a duplicate event that must pass
before the multiple-event counter of log entry is updated. The values range from 1 to 255.
METW [60]
The Multiple Event Time Window is the number of minutes which must pass between
duplicate log entries which utilize a multiple-event counter. The values range from 0 to 99
minutes.
Custom Options
Log EFI Status Code [Enabled]
This option allows you to enable or disable logging of the EFI Status Codes.
Configuration options: [Disabled] [Enabled]
The following item appears only when Log EFI Status Code is set to [Enabled].
Convert EFI Status Codes to Standard Smbios Type [Disabled]
This option allows you to enable or disable converting of EFI Status Codes to Standard
Smbios Type (Not all may be translated).
Configuration options: [Disabled] [Enabled]
