5-52

Chapter 5: BIOS Setup

The following item appears only when Boost FmaxEn is set to [Manual].

Power Package Limit [0]

This item allows you to specify the boost Fmax frequency limit to apply to all cores

(MHz).

NBUI RAS Common Options

NBIO RAS Global Control [Auto]

Configuration options: [Auto] [Manual]

NBIO RAS Control [Auto]

Configuration options: [Disabled] [MCA] [Legacy] [Auto]

Egress Poison Severity High [30011]

Each bit set to 1 enables HIGH severity on the associated IOHC egress port. A bit of 0

indicates LOW severity.

Egress Poison Severity Low [4]

Each bit set to 1 enables HIGH severity on the associated IOHC egress port. A bit of 0

indicates LOW severity.

NBIO SyncFlood Generation [Auto]

This value may be used to mask SyncFlood caused by NBIO RAS options. When set

to TRUE, SyncFlood from NBIO is masked. When set to FALSE, NBIO is capable of

generating SyncFlood.

Configuration options: [Disabled] [Enabled] [Auto]

NBIO SyncFlood Reporting [Disabled]

This value may be used to enable SyncFlood reporting to APML. When set to TRUE,

SyncFlood will be reported to APML. When set to FALSE, the reporting will be

disabled.

Configuration options: [Disabled] [Enabled]

Egress Poison Mask High [fffcffff]

These set the enable mask for masking of errors logged in EGRESS_POISON_

STATUS. For each bit set to 1, errors are masked. For each bit set to 0, errors trigger

response actions.

Egress Poison Mask Low [fffffffb]

These set the enable mask for masking of errors logged in EGRESS_POISON_

STATUS. For each bit set to 1, errors are masked. For each bit set to 0, errors trigger

response actions.

Uncorrected Converted to Poison Enable Mask High [30000]

These set the enable mask for masking of uncorrectable parity errors on internal

arrays. For each bit set to 1, a system fatal error event is triggered for UCP errors on

arrays associated with that egress port. For each bit set to 0, errors are masked.
