SiBE12-728 Troubleshooting
Service Diagnosis 233
5.2 Outdoor Units
4
: ON,
1
: OFF,
5
: Blinks
Green : Flashes when in normal condition
Red : OFF in normal condition
- : Not used for troubleshooting
∗
: Varies depending on the cases.
Note: 1. The indications in the parenthesis ( ) in the remote controller display column are displayed
only when system-down occurs.
2. When a sensor error occurs, check the remote controller display to determine which sensor
is malfunctioning.
If the remote controller does not indicate the error type, conduct the following operation.
*Turn the power switch off and back on again. If the same LED indication appears again
immediately after the power is turned on, the fault is in the thermistor.
*If the above condition does not result, the fault is in the CT.
3. The indoor unit error indication may take the precedence in the remote controller display.
Outdoor Unit LED Indication Indication on
the remote
controller
Description of The Fault
Reference
Page
Gree
n
Red
A12345
53333300
Outdoor unit in normal condition
(Conduct a diagnosis of the indoor unit.)
—
UA
Unspecified voltage (between indoor and outdoor units)
272
UH
Anti-icing function in other rooms
272
533443 (U0)
Insufficient gas
268
543343U2
Low-voltage detection or over-voltage detection
270
534443U7
Signal transmission error (on outdoor unit PCB)
271
543443A5
Freeze-up protection control
244
544433E1
Outdoor unit PCB abnormality
246
543433 (E5)
OL activation (compressor overload)
247
534433 (E6)
Compressor lock
248
544443E7
DC fan lock
249
534343E8
Input over current detection
250
543433F3
Discharge pipe temperature control
252
543443F6
High pressure control in cooling
253
544333H0
Compressor sensor system abnormality
255
H8
CT or related abnormality
258
544333H6
Position sensor abnormality
257
H9
Outdoor air thermistor or related abnormality
260
J3
Discharge pipe thermistor or related abnormality
260
J6
Heat exchanger thermistor or related abnormality
260
J8
Liquid pipe thermistor or related abnormality
260
J9
Gas pipe thermistor or related abnormality
260
P4
Radiation fin thermistor or related abnormality
260
544343L3
Electrical box temperature rise
262
533343L4
Radiation fin temperature rise
(Protection of driver overheating)
264
533433L5
Output over current detection
266
