SiBE12-728 Specifications
Specifications 29
50Hz 230V
Model
FTXS71FV1B
Cooling Heating
Rated Capacity 7.1kW Class
Front Panel Color White
Air Flow Rates
m³/min
(cfm)
H 17.4 (614) 19.7 (696)
M 14.6 (516) 16.9 (597)
L 11.6 (410) 14.3 (505)
SL 10.6 (374) 12.7 (448)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof
Running Current (Rated) A 0.20 0.27
Power Consumption (Rated) W 45 60
Power Factor % 97.8 96.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46/42/37/34 46/42/37/34
Sound Power H dBA 62 62
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
Gas mm
φ
15.9
Drain mm
φ
18.0
Drawing No. 3D056021
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
