SiBE18-821 Indoor Unit (SkyAir Models)
Function 101
8.2 Electric Function Parts
FFQ – B8V1B
FHQ – BVV1B
Capacity 25 35 50 60 Remarks
Wired remote controller BRC1C517 Optional
Accessory
Wireless remote
controller
Heat pump BRC7EA530W
Optional
Accessory
Cooling only BRC7EA531W
Electronic control unit [2P095006-8] EC0608
Fan motor [3P104408-1] 4P 55W
Fan motor capacitor 4µF [440VAC]
Float switch [4P104167-1] FS-0211B
Drain pump [3P103929-1]
PLD-12230DM-17
Capacity 35 50 60 Remarks
Wired remote controller BRC1D528 Optional
Accessory
Wireless remote
controller
Heat pump BRC7EA63W
Optional
Accessory
Cooling only BRC7EA66
Electronic Control Unit [2P095007-7]
EC0606
Fan Motor [3PN04213-1] 4P 62W
Fan Motor Capacitor 3.0µF 440VAC
Swing Motor [3PN04208-1]
