SiBE18-821 Field Setting for SkyAir Indoor Unit
Test Operation 155
4.4 Local Setting Mode Number
Example To set the filter sign time to “filter contamination - heavy” for all units in a group:
Set mode No. to “10,” setting switch No. to “0,” and setting position No. to “02.”
Table (FHQ & FFQ)
Mode
No.
Note 1
Setting
Switch
No.
Setting Description Setting Position No. *Note 2
01 02 03
10
(20)
0 Filter contamination - heavy /
light (Setting of operating
hours for filter sign indication)
(Change setting when
reducing filter sign indication
time to half due to quick soiling
of filter)
Long-Life
Type
Light Approx.
2,500
hours
Heavy Approx.
1,250
hours
—
1 Long-life filter type (Setting of filter sign
indication time)
(Change setting when Ultra-long-life filter is
installed)
Long-Life Filter — —
2 Remote control thermostat
(Set when remote control thermostat sensor
is used.)
Use Not use
3 Estimation of filter operating hour
(Change setting when filter sign indication is
not used)
ON OFF —
11
(21)
2 Indoor unit fan OFF when thermostat OFF in
cooling/heating
—Fan OFF—
12
(22)
5 Automatic restart after power failure reset
*Note 4
OFF ON —
13
(23)
0 High
Ceiling
Ceiling-suspended type (FHQ
only)
2.7 m or Lower 2.7~3.5 m —
1 Airflow direction selection (Change setting
when blocking kit is installed) *Note 3
FTW
4 Setting of airflow direction adjustment range Upward Standard Downward
